Lazer Grille Kit Ford Ranger Limited 2023- (Triple-R 850)



Lazer Grille Integration Kits include bespoke mounting brackets which allow for quick and easy fitting of Lazer High Performance LED Spotlights within the front grille of the most popular road cars, pick-up trucks, and light commercial vehicles.

Designed to blend seamlessly within the original styling of each vehicle, the resulting lighting setup remains fully robust and secure, with extra protection against theft.

TheRanger limited kit, designed for 2023- vehicles onwards, includes a pair of Triple-R 850 High Performance LED driving lights, plus wiring kit, alongside 4x brackets precision-engineered to engage perfectly with the standard centre grille on the vehicle.



Product Features:

• Custom fit for Ford Ranger Limited 2023- models
• Designed for use with Triple-R 850 High Performance LED Spotlights
• Added option for white or amber position/side light function (Standard model only)
• Kit also includes bespoke mounting brackets and two-lamp wiring kit
• Brackets made from high strength, UV-stable, composite material
• Installation completed with grille left in-situ on vehicle
• Fully road-legal
• 5-year warranty



Technical Specifications: Elite / STD

• Voltage range: 10-32V
• Weight: 3 Kg
• Total luminous: 16136 Lm / 13860 Lm
• Colour temperature: 5000K
• Power consumption: 146 W / 132 W
• Current draw: 10,2A / 10,2A
• High beam (E9 approval): ECE R112 / ECE R112
• Reference: 17,5 x 2 (E-mode) / 45 x 2
• Position light: Ei / Kyllä / Ei



Photometric data:

• Horisontal / Vertical beam angle : (42°/18°)  / (19°/18°)
• 0,25 Lux: 1634m / 1500m
• 0,5 Lux: 1162m / 1061m
• 1 Lux: 822m / 750m
• 3 Lux: 474m / 433m



What's Included:

• Grille Mounting Kit
• 2x Triple-R 850 LED Lamps
• Two-Lamps Wiring Kit
• Installation Instructions
